BMW 3 series F30/F31 facelift (2015-2020) turn indicator/ side marker light led module Wiring diagram
This page shows the only wiring diagram for the component.turn indicator/ side marker light led module, which is found in the car BMW 3 series F30/F31 facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn indicator/ side marker light led module (1 of 1)
ACCENT LIGHT
BLU/BRN (OR BLU) WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECTION IND
DRIVER EXTERIOR MIRROR
FRONT PASSENGER EXTERIOR MIRROR
FRONT POWER DISTRIBUTION BOX
FUSE 100
FUSE 40
HOT AT ALL TIMES
LEFT FOOTWELL)
LEFT FRONTAL LIGHT ELECTRONICS
LEFT HEADLIGHT
REAR FUSE HOLDER
RED/BLK WIRE
RIGHT FRONTAL LIGHT ELECTRONICS
RIGHT HEADLIGHT
SIDE LIGHTS/DAYTIME DRIVING LIGHTS LED MODULE
SIDE MARKER LIGHT
SIDE REPEATER LAMP
TURN INDICATOR/ SIDE MARKER LIGHT LED MODULE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, w/ led headlamps (3 of 3) -> TURN INDICATOR/ SIDE MARKER LIGHT LED MODULE
