BMW 3 series F30/F31 facelift (2015-2020) mirror fold in drive lane change warning led Wiring diagram
This page shows the only wiring diagram for the component.mirror fold in drive lane change warning led, which is found in the car BMW 3 series F30/F31 facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror fold in drive lane change warning led (1 of 1)
ADJUSTMENT
ALL ROUND VISION CAMERA (LEFT END OF DASH)
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE
DRIVER EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
ELECTROCHROMIC
EXTERIOR MIRROR CAMERA
FRONT ELECTRONIC MODULE
FRONT PASSENGER EXTERIOR MIRROR
FRONT POWER DISTRIBUTION BOX
FUSE 22
GRN WIRE
GRY WIRE
K CAN H
K CAN L
LANE CHANGE WARNING LED
LEFT FOOTWELL)
LIN
MIRROR
MIRROR FOLD IN DRIVE LANE CHANGE WARNING LED
MIRROR FOLD- IN DRIVE
MIRROR HEATING
NCA WIRE
ORG/ WIRE
RED WIRE
RED/GRY WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SENSORS
SIDE REPEATER
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Memory mirrors circuit, w/ lin bus function -> MIRROR FOLD IN DRIVE LANE CHANGE WARNING LED
