BMW 3 series F30/F31 facelift (2015-2020) memory function hall sensor Wiring diagram
This page shows the only wiring diagram for the component.memory function hall sensor, which is found in the car BMW 3 series F30/F31 facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory function hall sensor (1 of 1)
BLK/WHT WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT MODULE
DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE UNIT
DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE
DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT
DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT ELECTRONIC MODULE
FRONT POWER DISTRIBUTION BOX
FUSE 67
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/YEL WIRE
K CAN
LEFT FOOTWELL)
MEMORY FUNCTION HALL SENSOR
ORG/ WIRE
ORG/GRN WIRE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SEATS SYSTEM
SERVO MOTOR
VIO/BRN WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Driver"s memory seat circuit -> MEMORY FUNCTION HALL SENSOR
