2.0l turbo, starting circuit for BMW 3 series F30/F31 (2011-2015)

13 14 PNK WIRE 47 48 40 29 28 13 PNK WIRE BATTERY BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE CHARGING CIRCUIT CLUTCH MODULE (M/T) (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (TOP REAR OF ENGINE) ELECTRIC MACHINE ELECTRONICS (ATTACHED TO FRONT ELECTRONIC MODULE (RIGHT END OF DASH) FRONT POWER FUSE DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/BLU WIRE GRN/YEL WIRE HOT AT ALL TIMES INTELLIGENT BATTERY SENSOR (ON BATTERY NEGATIVE POST) JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) NCA WIRE POSITIVE BATTERY CONNECTION POINT RED WIRE RED/BLU WIRE REVERSE POLARITY PROTECTION SAFETY BATTERY TERMINAL GENERATOR START-STOP BUTTON START-STOP FUNCTION STARTER TRANSFER TERMINAL POINT VIO/YEL WIRE W/O AUTOMATIC ENGINE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
