Driver"s memory seat circuit, coupe for BMW 3 series F30/F31 (2011-2015)

BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT ADJUSTMENT SWITCH DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE (UNDER DRIVER SEAT) DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT MOTOR (UNDER DRIVER SEAT) DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT (UNDER DRIVER SEAT) DRIVER'S SEAT MODULE DRIVER'S SIDE EASY ENTRY SWITCH ELECTRONICS JUNCTION BOX FUSE 46 GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RELAY ENERGIZED FUSE 77 SEATS SYSTEM VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

BLU WIRE BRN/VIO WIRE CENTER CONSOLE SWITCH CENTER DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER SEAT) HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH, ABOVE RADIO) NCA WIRE RED/YEL WIRE VIO WIRE VIO/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE
