Wiring diagram trg act neg trg act pos trg act pos trg act neg (1 of 2)
AIR BAG ACT POS AIR BAG ACT NEG
AIR BAG ACT POS AIR BAG ACT NEG AIR BAG ACT NEG AIR BAG ACT POS
BELT TENS ACT POS BELT TENS ACT NEG BELT TENS ACT NEG BELT TENS ACT POS
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE (REAR OF CENTER CONSOLE)
DRIVER RETRACTOR TENSIONER
DRIVER'S AIR BAG INFLATOR ASSEMBLY
DRIVER'S KNEE AIR BAG INFLATOR ASSEMBLY
FRONT PASSENGER RETRACTOR TENSIONER
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT FRONT SEAT BELT FORCE LIMITER GENERATOR
LEFT HEAD AIR BAG INFLATOR ASSEMBLY (LEFT HEADLINER)
NCA WIRE
PASSENGER'S KNEE AIR BAG INFLATOR ASSEMBLY
PASSENGER'S SIDE AIR BAG INFLATOR ASSEMBLY (RIGHT SIDE OF PASSENGER SEAT BACK)
RED WIRE
RIGHT FRONT SEAT BELT FORCE LIMITER GENERATOR
SAFETY BATTERY TERMINAL 2 ALTERNATOR (HYBRID)
STEERING COLUMN SWITCH CLUSTER
TRG ACT NEG TRG ACT POS TRG ACT POS TRG ACT NEG
VIO/GRN WIRE
VIO/WHT WIRE
W-UP TER 15
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> TRG ACT NEG TRG ACT POS TRG ACT POS TRG ACT NEG
