BMW 3 series F30/F31 (2011-2015) terminal 15 cond wel spd pt can high ground Wiring diagrams
This page contains all the electrical diagrams for the component. terminal 15 cond wel spd pt can high ground, in which he is found in the car BMW 3 series F30/F31 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram terminal 15 cond wel spd pt can high ground (1 of 2)
BLU WIRE
BLU/BRN/YEL WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT)
BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH)
BRK FLD LVL RF WHL SPD
BRN WIRE
BRN/BLK WIRE
BRN/GRN/YEL WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT)
EDC ELECTRONIC DAMPER CONTROL (RIGHT SIDE OF REAR COMPT)
FUSE
GRN/RED WIRE
GROUND F-CAN-LOW
HAZARD WARNING SWITCH
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT FRONT BRAKE PAD WEAR SENSOR (BEHIND LEFT FRONT WHEEL)
LEFT REAR WHEEL SPEED SENSOR (BEHIND LEFT REAR WHEEL)
NCA WIRE
PARKING BRAKE WARNING SWITCH (UNDER CENTER CONSOLE)
RED WIRE
RED/ BLU WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RF WHL SPD RR WHL SPD LR WHL SPD LF WHL SPD LF WHL SPD
RIGHT REAR BRAKE PAD WEAR SENSOR (FRONT OF RIGHT REAR WHEEL)
RIGHT REAR WHEEL SPEED SENSOR (BEHIND RIGHT REAR WHEEL)
RR BRK PAD
RR WHL SPD
RR WHL SPP
SEN GROUND
STEERING COLUMN SWITCH CLUSTER
TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT)
TERMINAL 15 COND WEL SPD PT CAN HIGH GROUND
VIO/WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Anti-lock brakes circuit, except sedan with bosch dsc -> TERMINAL 15 COND WEL SPD PT CAN HIGH GROUND
