BMW 3 series F30/F31 (2011-2015) reverse polarity protection Wiring diagram
This page shows the only wiring diagram for the component.reverse polarity protection, which is found in the car BMW 3 series F30/F31 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reverse polarity protection (1 of 1)
13 14 PNK WIRE
47 48 40 29 28 13 PNK WIRE
BATTERY
BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
CHARGING CIRCUIT
CLUTCH MODULE (M/T) (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (TOP REAR OF ENGINE)
ELECTRIC MACHINE ELECTRONICS (ATTACHED TO
FRONT ELECTRONIC MODULE (RIGHT END OF DASH)
FRONT POWER
FUSE DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
INTELLIGENT BATTERY SENSOR (ON BATTERY NEGATIVE POST)
JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT)
NCA WIRE
POSITIVE BATTERY CONNECTION POINT
RED WIRE
RED/BLU WIRE
REVERSE POLARITY PROTECTION
SAFETY BATTERY TERMINAL GENERATOR
START-STOP BUTTON
START-STOP FUNCTION
STARTER
TRANSFER TERMINAL POINT
VIO/YEL WIRE
W/O AUTOMATIC ENGINE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> 2.0l turbo, starting circuit -> REVERSE POLARITY PROTECTION
