BMW 3 series F30/F31 (2011-2015) rear driver's side seat backrest heating element Wiring diagram
This page shows the only wiring diagram for the component.rear driver's side seat backrest heating element, which is found in the car BMW 3 series F30/F31 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear driver's side seat backrest heating element (1 of 1)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
FUSE
FUSE 141
FUSE 164 HOLDER (RIGHT SIDE OF REAR COMPT)
GRN/VIO WIRE
GRY WIRE
LEFT REAR SEAT HEATING SWITCH
REAR DRIVER'S SIDE SEAT BACKREST HEATING ELEMENT
REAR DRIVER'S SIDE SEAT CUSHION HEATING ELEMENT
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR FUSE
REAR PASSENGER'S SIDE SEAT BACKREST HEATING ELEMENT
REAR PASSENGER'S SIDE SEAT CUSHION HEATING ELEMENT
REAR PASSENGER'S SIDE SEAT HEATING MODULE
RED/BRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT REAR SEAT HEATING SWITCH
WHT/BRN WIRE
Go to component -> Rear heated seats circuit -> REAR DRIVER'S SIDE SEAT BACKREST HEATING ELEMENT
