BMW 3 series F30/F31 (2011-2015) power windows system power windows system headlights system Wiring diagram
This page shows the only wiring diagram for the component.power windows system power windows system headlights system, which is found in the car BMW 3 series F30/F31 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power windows system power windows system headlights system (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/GRY/WHT WIRE
BRN/GRY/YEL WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM
DOOR LOCKS SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM
FOOTWELL MODULE (UNDER LEFT SIDE OF DASH)
FUSE 41
FUSE 81
FUSE 86 BOX (UNDER RIGHT SIDE OF DASH)
GRN/YEL WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
HOT AT ALL TIMES
JUNCTION
POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM HEADLIGHTS SYSTEM
POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
VIO WIRE
VIO/BRN WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Footwell control module circuit (2 of 2) -> POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM HEADLIGHTS SYSTEM
