BMW 3 series F30/F31 (2011-2015) knock sensor cylinder cylinder 4-6 1-3 Wiring diagram
This page shows the only wiring diagram for the component.knock sensor cylinder cylinder 4-6 1-3, which is found in the car BMW 3 series F30/F31 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram knock sensor cylinder cylinder 4-6 1-3 (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
CHARGING STARTING/
DME CONTROL MODULE
ENGINE ELECTRONICS FUSE CARRIER (RIGHT PLENUM CHAMBER E-BOX)
FUSE 1
FUSE 102
FUSE 2
FUSE 4
GRY WHT/ WIRE
HOT AT ALL TIMES
IGNITION, FUEL INJECTION RELAY
JUMP START TERMINAL POINT
KNOCK SENSOR CYLINDER CYLINDER 4-6 1-3
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
RED WIRE
RED/GRN WIRE
SYSTEM
VALVETRONIC RELAY
VIO WIRE
VOLUME CONTROL VALVE
WASTEGATE VALVE PRESSURE CONVERTER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (2 of 5) -> KNOCK SENSOR CYLINDER CYLINDER 4-6 1-3
