gry wiring diagram (41 of 145)

BLK WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CAR INFORMATION COMPUTER CIC COMFORT ACCESS CONTROL UNIT (RIGHT SIDE OF REAR COMPT) COMPUTER DATA LINES SYSTEM COUPE CONVERTIBLE ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FBD RECEIVER FRONT INNER ANTENNA CENTER CONSOLE GRN WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/GRN WIRE PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE REAR FENDER AERIAL REAR INNER ANTENNA LUGGAGE COMPARTMENT REAR INTERIOR ANTENNA CENTER CONSOLE RED WIRE RED/VIO WIRE RED/YEL WIRE REMOTE CONTROL RECEIVER ROOF ANTENNA SLIDE-IN COMPARTMENT SOUND SYSTEMS START-STOP BUTTON WHT WIRE WHT/BLK WIRE WHT/GRN WIRE

Go to component -> Access/start circuit, except sedan (2 of 2) -> GRY WIRE

gry wiring diagram (42 of 145)

AERIAL SIG BLK WIRE BLK/BRN WIRE BLK/RED WIRE BRN WIRE BRN/BLK WIRE BUMPER AERIAL COMPUTER DATA LINES SYSTEM DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE DRIVER SIDE EXTERNAL ANTENNA FRONT ELECTRONIC MODULE (RIGHT END OF DASH) FRONT PASSENGER SIDE EXTERNAL ANTENNA GRN/BLU WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE LUGGAGE COMPARTMENT AERIAL PASSENGER ELECTRONIC OUTER DOOR HANDLE MODULE RED/YEL WIRE RING AERIAL SIG START-STOP BUTTON STEERING COLUMN SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Access/start circuit, sedan (2 of 2) -> GRY WIRE

gry wiring diagram (43 of 145)

BLU WIRE BLU/RED WIRE BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT) BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH) BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER CONSOLE OPERATING UNIT COMPUTER DATA LINES SYSTEM DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT) FUSE 29 FUSE 404 FUSE 58 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ LEFT FRONT BRAKE PAD WEAR SENSOR (BEHIND LEFT FRONT WHEEL) LEFT FRONT WHEEL SPEED SENSOR (BEHIND LEFT FRONT WHEEL) LEFT REAR WHEEL SPEED SENSOR (BEHIND LEFT REAR WHEEL) NCA WIRE PARKING BRAKE WARNING SWITCH (UNDER CENTER CONSOLE) PNK/BLK WIRE PNK/BLU WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT WHEEL SPEED SENSOR (BEHIND RIGHT FRONT WHEEL) RIGHT REAR BRAKE PAD WEAR SENSOR (FRONT OF RIGHT REAR WHEEL) RIGHT REAR WHEEL SPEED SENSOR (BEHIND RIGHT REAR WHEEL) STEERING COLUMN SWITCH CLUSTER WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE

Go to component -> Anti-lock brakes circuit, sedan -> GRY WIRE

gry wiring diagram (44 of 145)

2.0L TURBO 2.0L TURBO 200W 2.0L TURBO 400W, 2.0L TURBO EXCEPT SULEV, 3.0L TURBO 335I, 3.0L TWIN 2.0L TURBO SULEV 4 13 28 18 CUT-OUT RELAY PT-CAN BUS SIG PT-CAN BUS SIG ELEC FAN 41 46 17 35 24 53 BSD BUS SIG SPLY PUMP 46 37 25 54 SPLY MAP MAP THERMOSTAT TEMP SENS TEMP SENS SIG BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CHARACTERISTIC MAP THERMOSTAT (3.0L TWIN TURBO: REAR OF ENGINE) COMPUTER DATA LINES SYSTEM ELECTRIC COOLANT PUMP (REAR OF ENGINE) ELECTRIC COOLANT PUMP 2 ELECTRIC FAN (FRONT OF ENGINE COMPT) ELECTRIC FAN CUT OUT RELAY ENGINE CONTROLS SYSTEM EVAPORATOR FOOTWELL TEMPERATURE TEMPERATURE SENSOR SENSOR (CENTER OF DASH) FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT) FUSE FUSE 29 GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES POWER DISTRIBUTION BOX HOT W/ MANAGEMENT ELECTRONICS ACCUMULATOR (HYBRID) RADIATOR OUTLET TEMPERATURE SENSOR (2.0L TURBO SULEV) (RIGHT SIDE OF ENGINE) RED WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE REFRIGERANT SHUT-OFF VALVE (HIGH VOLTAGE BATTERY) (HYBRID) RELAY ENERGIZED SHUT-OFF VALVE VENTILATION TEMPERATURE SENSOR (CENTER OF DASH) VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE

Go to component -> Automatic a/c circuit, sedan (2 of 3) -> GRY WIRE

gry wiring diagram (45 of 145)

ALTERNATOR BATTERY BATTERY SENSOR (RIGHT SIDE OF REAR COMPT) BRN WIRE COMPUTER DATA LINES SYSTEM DME CONTROL UNIT (RIGHT REAR OF ENGINE COMPT) FUSE 105 N/A GRN WIRE GRY WIRE JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) LUGGAGE WELL B+ TERMINAL POINT NCA WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE STARTER VIO WIRE

Go to component -> Charging circuit -> GRY WIRE

gry wiring diagram (46 of 145)

18 19 PT CAN L PT CAN H 33 34 9 10 51 52 FLEX BUS SIG FLEX BUS SIG 36 45 30 DATA LINE BUS SIG DIAG FLEX BUS SIG 42 27 K-LIN K-LIN-1 AC LINE ACTIVE SOUND DESIGN BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER OUTPUT STAGE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE BUS SIG BUS SIG BUS SIG PT CAN L PT CAN H BUS SIG BUS SIG (OR PNK) WIRE BUS SIG DIAG DATA LINE CAN L CENTER OF WINDSHIELD) DATA LINE DATA LINE PNK PNK BUS SIG WIRE DRIVER'S DOOR SWITCH BLOCK DRIVER'S EXTERIOR MIRROR ELECTROCHROMIC INTERIOR REARVIEW MIRROR ELECTRONIC DAMPER CONTROL (RIGHT REAR OF LUGGAGE COMPT) FRONT ELECTRONIC MODULE (FEM) (RIGHT END OF DASH) FRONT PASSENGER EXTERIOR MIRROR FUSE FUSE 12 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE HEAD UNIT HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH, ABOVE RADIO) HIFI AMPLIFIER HIGH VARIANT ROOF FUNCTION MODULE HOT AT ALL TIMES FUSE BOX INSTRUMENT CLUSTER CONTROL MODULE K CAN BUS K CAN BUS K LINE K-LIN K-LIN-1 LIGHT SWITCH UNIT LIN BUS SIG ORG/ WIRE ORG/GRN WIRE PNK 13 14 15 16 17 18 19 20 21 22 23 WIRE PNK 24 25 26 27 WIRE PNK BUS SIG BUS SIG WIRE PNK PNK FLEX BUS SIG WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/RED WIRE PNK/WHT WIRE PT CAN H PT CAN L RED WIRE RED/BLU WIRE RELAY ENERGIZED RWD SPLY STEERING COLUMN SWITCH CLUSTER WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Computer data lines circuit, sedan (1 of 3) -> GRY WIRE

gry wiring diagram (47 of 145)

1 14 16 4 CAN L CAN H BRAKE LIGHT BRAKE LIGHT ANTI-THEFT SYSTEM BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH) BRN WIRE BRN/GRY WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FUSE GRY WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) RED WIRE RELAY ENERGIZED SHIFT LOCK SELECTOR LEVER LOCK (BASE OF SHIFT LEVER ASSEMBLY) TRANSMISSION CONTROL TRANSMISSIONS SYSTEM VIO WIRE YEL WIRE

Go to component -> Shift interlock circuit -> GRY WIRE

gry wiring diagram (48 of 145)

A/T BATTERY BLK WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CLUTCH SWITCH MODULE (UNDER LEFT SIDE OF DASH) DME CONTROL UNIT (RIGHT REAR OF ENGINE COMPT) DOUBLE CLUTCH TRANSMISSION GRN/YEL WIRE GRY WIRE JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) LUGGAGE WELL B+ TERMINAL POINT M/T RED WIRE SIDE-IN COMPARTMENT START-STOP BUTTON STARTER TRANSMISSION CONTROL TRANSMISSION CONTROL DKG (BOTTOM OF TRANSMISSION) VIO WIRE WHT WIRE YEL WIRE

Go to component -> Starting circuit -> GRY WIRE

gry wiring diagram (49 of 145)

2.0L TURBO BLK WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC STEERING WHEEL MODULE (IN STEERING WHEEL) ELECTRONIC TRANSMISSION CONTROL (INSIDE BOTTOM OF TRANSMISSION) EXCEPT 2.0L TURBO FANFARE HORN BUTTON FRONT POWER DISTRIBUTION BOX FUSE 54 FUSE 24 (RIGHT REAR OF ENGINE COMPT) GEAR SELECTOR SWITCH GRN WIRE GRN/RED WIRE GRY WIRE HOT W/ TERMINAL LEFT SHIFT PADDLE RED WIRE RED/GRY WIRE RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK RIGHT SHIFT PADDLE STEERING COLUMN SWITCH CLUSTER WHT/BLU WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Transmission circuit -> GRY WIRE

gry wiring diagram (50 of 145)

22 23 35 36 OUT TEMP SIG OUT TEMP SIG PT-CAN BUS PT-CAN BUS 23 24 WIND WIPERS WASHER PUMP 33 34 36 22 OUT SENS SIG OUT SENS SIG RESET CTRL SIG WIND WIPERS 41 3 48 36 LIN BUS SIG WASH-NOZZLE WASHER PUMP WASHER PUMP BLK WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BOX (RIGHT REAR OF ENGINE COMPT) BRN WIRE BRN/BLK WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FEM FRONT ELECTRONIC MODULE (RIGHT END OF DASH) FRONT POWER DISTRIBUTION FUSE FUSE BOX GRN/BLK WIRE GRY WIRE GRY/VIO WIRE HEADLIGHT WASHER PUMP (BEHIND RIGHT FRONT WHEEL) HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL UNIT LEFT WASHER NOZZLE HEATER LEVEL SENS OUTSIDE TEMPERATURE SENSOR (FRONT CENTER OF BUMPER) RAIN/LIGHT/ CONDENSATION/SOLAR SENSOR (TOP CENTER OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED FUSE 28 RIGHT WASHER NOZZLE HEATER TERM 30 SUPPLY VIO WIRE WASHER FLUID LEVEL SENSOR WINDSHIELD WIPERS

Go to component -> Wiper/washer circuit -> GRY WIRE
