BMW 3 series F30/F31 (2011-2015) grn Wiring diagrams

This page contains all the electrical diagrams for the component. grn, in which he is found in the car BMW 3 series F30/F31 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

grn wiring diagram (201 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (201 of 275)

1 2 MOST DATA BUS CIRCUIT AERIAL AMPLIFIER BASE PLATE BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 121 FUSE 124 FUSE 155 FUSE 127 GPS ANTENNA GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL MOST DATA BUS CIRCUIT NCA WIRE NOISE SUPPRESSOR FILTER ORG/ WIRE ORG/GRN WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) REAR WINDOW ANTENNA REAR WINDOW DEFOGGER REJECTOR CIRCUIT REAR WINDOW DEFOGGER REJECTOR CIRCUIT 2 RED WIRE RED/VIO WIRE RED/YEL WIRE ROOF AERIAL VIDEO MODULE (LEFT SIDE OF REAR COMPT) VIO WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Base radio circuit, sedan (1 of 2) -> GRN WIRE

grn wiring diagram (202 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (202 of 275)

ALL ROUND VISION CAMERA (LEFT KICK PANEL) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE CENTRAL INFORMATION DISPLAY DVD CHANGER GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT REAR MID-RANGE SPEAKER MICROPHONE MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR MID-RANGE SPEAKER VIO WIRE W/ DVD CHANGER W/ NAVIGATION SYSTEM PROFESSIONAL W/ OPTIONAL EQUIPMENT W/ VIDEO MODULE W/ VIDEO MODULE, DVD CHANGER W/O ALL ROUND VISION CAMERA W/ VIDEO MODULE, W/O DVD CHANGER W/O NAVIGATION SYSTEM PROFESSIONAL W/O OPTIONAL EQUIPMENT W/O VIDEO MODULE W/O W/ VIDEO VIDEO MODULE, DVD MODULE CHANGER W/O ALL ROUND VISION CAMERA WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

Go to component -> Base radio circuit, sedan (2 of 2) -> GRN WIRE

grn wiring diagram (203 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (203 of 275)

1 2 (PIN 3-4 NOT USED) 5 6 7 8 (PIN 9-10 NOT USED) 11 12 1 2 3 4 5 6 (PIN 7-10 NOT USED) 11 12 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 (PIN 16-38 NOT USED) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CCC/M-ASK CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) ELECTRONICS JUNCTION BOX FAN M-ASK/CCC FUSE FUSE 18 FUSE 19 FUSE 27 GPS GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT IN-BUMPER TV ANTENNA LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT IN-BUMPER TV ANTENNA ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS ANTENNA VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START/STOP FUNCTION W/O AUTOMATIC ENGINE START/STOP FUNCTION W/O BOSCH DSC W/ BOSCH DSC WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, convertible with ccc & m-ask (1 of 2) -> GRN WIRE

grn wiring diagram (204 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (204 of 275)

18 19 20 21 22 (PIN 23-26 NOT USED) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER DIGITAL TUNER ANTENNA DIGITAL TUNER ANTENNA 2 ELECTRONICS JUNCTION BOX FUSE FUSE 14 FUSE 18 FUSE 19 FUSE 27 GRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT IN-BUMPER TV ANTENNA REMOTE CONTROL RECEIVER LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE OBDII SOCKET (UNDER LEFT SIDE OF DASH) ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT IN-BUMPER TV ANTENNA ROOF ANTENNA GPS USB PORT VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Hifi radio circuit, convertible with cic (1 of 2) -> GRN WIRE

grn wiring diagram (205 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (205 of 275)

AMPLIFIER (LEFT SIDE OF REAR COMPT) ANTENNA DIVERSITY (CENTER REAR OF ROOF) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CONVERTIBLE TOP MODULE FM ANTENNA FM ANTENNA 1 FM ANTENNA 3 FUSE 15 GRN WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE SECTION ANTENNA AMPLIFIER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE REAR WINDOW ANTENNA AMPLIFIER REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE SECTION ANTENNA AMPLIFIER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS ANTENNA W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, convertible with cic (2 of 2) -> GRN WIRE

grn wiring diagram (206 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (206 of 275)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 (PIN 16-29 NOT USED) 30 31 32 33 34 35 36 AUX-IN CONNECTION AV SOCKET BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) COMPUTER DATA LINES SYSTEM CONTROLLER FUSE 14 FUSE 18 FUSE 19 FUSE 27 GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ JUNCTION BOX (UNDER RIGHT SIDE OF DASH) MOST-BUS CONNECTOR NCA WIRE ORG/GRN WIRE RADIO RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RELAY ENERGIZED ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS ANTENNA TELEPHONE RETROFIT PACKAGES CONNECTOR TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) W/ ANTENNA DIVERSITY W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/O ANTENNA DIVERSITY WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, convertible without cic, ccc & m-ask (1 of 2) -> GRN WIRE

grn wiring diagram (207 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (207 of 275)

1 2 (PIN 3-4 NOT USED) 5 6 7 8 (PIN 9-10 NOT USED) 11 12 1 2 3 4 5 6 (PIN 7-10 NOT USED) 11 12 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 (PIN 16-38 NOT USED) AERIAL DIVERSITY (CENTER REAR OF ROOF) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CCC/M-ASK CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM ELECTRONICS JUNCTION BOX FAN M-ASK/CCC 1 3 2 FUSE FUSE 18 GPS GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) VIDEO MODULE (LEFT SIDE OF REAR COMPT) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, coupe with ccc & m-ask (1 of 2) -> GRN WIRE

grn wiring diagram (208 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (208 of 275)

AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROLLER DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) EDC ELECTRONIC DAMPER CONTROL (RIGHT SIDE OF REAR COMPT) FUSE 15 FUSE 27 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE ORG/GRN WIRE REAR-WINDOW AERIAL RED WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER TCU TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/O BOSCH DSC W/ BOSCH DSC YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, coupe with ccc & m-ask (2 of 2) -> GRN WIRE

grn wiring diagram (209 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (209 of 275)

1 2 3 4 (PIN 5-10 NOT USED) AERIAL DIVERSITY (CENTER REAR OF ROOF) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER ELECTRONICS JUNCTION BOX FUSE FUSE 18 FUSE 19 FUSE 27 GRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE OBDII SOCKET 12 13 3 11 (UNDER LEFT SIDE OF DASH) ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED USB PORT W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Hifi radio circuit, coupe with cic (1 of 2) -> GRN WIRE

grn wiring diagram (210 of 275)

BMW 3 series F30/F31 (2011-2015) grn wiring diagram (210 of 275)

AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 15 GRN WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE REAR-WINDOW AERIAL RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER ROOF ANTENNA SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, coupe with cic (2 of 2) -> GRN WIRE
