BMW 3 series F30/F31 (2011-2015) front passenger's side seat adjustment switch block Wiring diagram
This page shows the only wiring diagram for the component.front passenger's side seat adjustment switch block, which is found in the car BMW 3 series F30/F31 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's side seat adjustment switch block (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER LUMBAR SUPPORT VALVE BLOCK (LEFT SIDE OF DRIVER SEAT BACK)
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
DRIVERS SEAT MODULE (UNDER DRIVER SEAT)
FRONT PASSENGER'S LUMBAR SUPPORT VALVE BLOCK (RIGHT SIDE OF PASSENGER SEAT BACK)
FRONT PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
FUSE 27 FUSE 68
GRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Sport seats circuit, sedan -> FRONT PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
