BMW 3 series F30/F31 (2011-2015) coolant level switch (right side of engine Wiring diagrams
This page contains all the electrical diagrams for the component. coolant level switch (right side of engine, in which he is found in the car BMW 3 series F30/F31 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram coolant level switch (right side of engine (1 of 3)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/RED/WHT WIRE
BLK/RED/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/BRN/YEL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLK/WHT WIRE
BRN/BLK/YEL WIRE
BRN/WHT WIRE
CENTRAL INFORMATION DISPLAY
COMPT)
COOLANT LEVEL SWITCH (RIGHT SIDE OF ENGINE
COUPE
ELECTRIC FUEL PUMP (RIGHT TANK HALF FUEL LEVEL SENSOR) (UNDER RIGHT REAR SEAT)
ELECTRONICS JUNCTION BOX
FUEL LEVEL SENSOR (UNDER LEFT REAR SEAT)
FUSE 74
GRN WIRE
INSTRUMENT CLUSTER CONTROL MODULE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT HALF TANK FUEL LEVEL SENSOR ELECTRIC FUEL PUMP (UNDER RIGHT REAR SEAT)
LEFT TANK HALF
ORG/ WIRE
ORG/GRN WIRE
OUTSIDE TEMPERATURE SENSOR (FRONT CENTER OF BUMPER)
PARKING BRAKE WARNING SWITCH (UNDER CENTER CONSOLE)
RED WIRE
RED/BLU WIRE
RIGHT HALF TANK FUEL LEVEL SENSOR
STEERING COLUMN SWITCH CENTER
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit -> COOLANT LEVEL SWITCH (RIGHT SIDE OF ENGINE
