BMW 3 series F30/F31 (2011-2015) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car BMW 3 series F30/F31 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (311 of 361)
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CLASSIFICATION RESISTOR (UNDER VEHICLE)
COMPUTER DATA LINES SYSTEM
FUSE 101 HOLDER (RIGHT SIDE OF REAR COMPT)
FUSE 26
FUSE 40
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
REAR FUSE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY
TERMINAL
TRANSFER BOX CONTROL MODULE (UNDER CARPET, ON RIGHT SIDE FOOTWELL)
VIO WIRE
VTG ACTUATOR (UNDER VEHICLE)
YEL WIRE
Go to component -> Awd circuit, coupe -> BRN WIRE
Wiring diagram brn (312 of 361)
2.0L TURBO
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT 2.0L TURBO
FRONT ELECTRONIC MODULE (RIGHT END OF DASH)
FRONT POWER DISTRIBUTION BOX
FUSE 32 (RIGHT REAR OF ENGINE COMPT)
FUSE 63
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
PNK WIRE
PNK/BLU WIRE
RED WIRE
TRANSFER BOX (BOTTOM REAR OF TRANSFER CASE)
VIO WIRE
YEL/GRN WIRE
Go to component -> Awd circuit, sedan -> BRN WIRE
Wiring diagram brn (313 of 361)
2 3 CONVERTIBLE COUPE
BLK WIRE
BLU WIRE
BOOT LID/ TAILGATE LUGGAGE COMPARTMENT LIGHT
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR EXIT LIGHT
DRIVER'S SIDE FOOTWELL LIGHT
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE (UNDER LEFT SIDE OF DASH)
FUSE 41
FUSE 77
FUSE 84
FUSE 86 FUSE 81
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT REAR LID LOCK SWITCH
LIGHT SWITCH UNIT
NCA WIRE
ORG/GRN WIRE
PASSENGER'S DOOR COURTESY LIGHT
PASSENGER'S DOOR ENTRANCE LIGHT
PASSENGER'S DOOR EXIT LIGHT
PASSENGER'S SIDE FOOTWELL LIGHT
REAR DRIVER'S SIDE DOOR COURTESY LIGHT
REAR INTERIOR LIGHT
REAR PASSENGER'S SIDE DOOR COURTESY LIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT LUGGAGE COMPARTMENT LIGHT
TOWING HITCH RELEASE (REAR OF VEHICLE)
TRUNK LID CENTRAL LOCKING DRIVE (ON REAR COMPT DOOR)
VIO WIRE
VIO/BRN WIRE
W/ LIGHT PACKAGE
W/O LIGHT PACKAGE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, coupe without roof function center -> BRN WIRE
Wiring diagram brn (314 of 361)
2 3 COUPE RIGHT LUGGAGE COMPARTMENT LIGHT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
COUPE CONVERTIBLE
DRIVER'S DOOR ENTRANCE LIGHT
ELECTRONICS JUNCTION BOX
FRONT INTERIOR LIGHT
FUSE 25
FUSE 41
FUSE 62
FUSE 7
FUSE 77
FUSE 84
FUSE 86 FUSE 81
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
HOT W/ TERMINAL 15 RELAY ENERGIZED
INTERIOR LIGHTS
JUNCTION BOX
LEFT FRONT MAKE UP MIRROR SWITCH
LEFT FRONT MAKE- UP MIRROR LIGHT
LEFT LUGGAGE COMPA- RTMENT LIGHT
LEFT REAR LID LOCK SWITCH
MAP READING LIGHT
ORG/GRN WIRE
PASSENGER'S DOOR ENTRANCE LIGHT
POWER DISTRIBUTION SYSTEM
REAR INTERIOR LIGHT (COUPE)
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT MAKE UP MIRROR SWITCH
RIGHT FRONT MAKE- UP MIRROR LIGHT
ROOF FUNCTION CONTROL CENTER
TOP LIGHT
TOWING HITCH RELEASE DRIVE UNIT (REAR OF VEHICLE)
TRUNK LID CENTRAL LOCKING DRIVE (ON REAR COMPT DOOR)
VIO WIRE
VIO/BRN WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, coupe with roof function center (1 of 2) -> BRN WIRE
Wiring diagram brn (315 of 361)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S SIDE FOOTWELL LIGHT
EXIT LIGHT
FRONT INTERIOR/ READING LIGHT (COUPE)
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LIGHT SWITCH UNIT
NCA WIRE
ORG/GRN WIRE
PASSENGER'S DOOR
PASSENGER'S DOOR COURTESY LIGHT
PASSENGER'S SIDE FOOTWELL LIGHT
REAR DRIVER'S SIDE DOOR COURTESY LIGHT
REAR INTERIOR LIGHT
REAR PASSENGER'S SIDE DOOR COURTESY LIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
VIO/BRN WIRE
W/ LIGHT PACKAGE
W/O LIGHT PACKAGE
YEL WIRE
Go to component -> Courtesy lamps circuit, coupe with roof function center (2 of 2) -> BRN WIRE
Wiring diagram brn (316 of 361)
BACKREST
BRN WIRE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER SEAT)
DRIVER'S SIDE BACKREST ANGLE ADJUSTMENT MOTOR (UNDER DRIVER SEAT)
FUSE 45
FWD/BWD
GRN WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
RED WIRE
RELAY ENERGIZED
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> BRN WIRE
Wiring diagram brn (317 of 361)
BLK WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
ELECTRONICS JUNCTION BOX
FANFARE HORN
FUSE 57
GRN WIRE
HORN SWITCH
HOT AT ALL TIMES REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) FUSE 101
JUNCTION BOX
LEFT HORN (LEFT SIDE OF FRONT BUMPER)
RED WIRE
RELAY
RIGHT HORN (RIGHT SIDE OF FRONT BUMPER)
STEERING COLUMN SWITCH CLUSTER
TERMINAL 15 RELAY
VIO/BLU WIRE
Go to component -> Horn circuit, coupe -> BRN WIRE
Wiring diagram brn (318 of 361)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 25
FUSE 62
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
ROOF FUNCTION CONTROL CENTER
SLIDE/TILT SUNROOF DRIVE UNIT (ROOF CONSOLE)
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Power top/sunroof circuit, coupe -> BRN WIRE
Wiring diagram brn (319 of 361)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER
FUSE 20
FUSE 62
FUSE DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
HIGH VARIANT ROOF FUNCTIONS MODULE
HOT AT ALL TIMES
HOT W/
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
SLIDE/TILT SUNROOF DRIVE UNIT (ROOF CONSOLE)
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power top/sunroof circuit, sedan -> BRN WIRE
Wiring diagram brn (320 of 361)
ACCELERATOR PEDAL MODULE (PART OF ACCELERATOR PEDAL)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
CLUTCH SWITCH MODULE (M/T) (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM ANTI-THEFT SYSTEM
COOLING FANS SYSTEM
DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
DME RELAY
FUEL TANK LEAKAGE DIAGNOSTIC MODULE
FUSE 101
FUSE 37
FUSE FUSE FUSE FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
MOTOR POSITION SENSOR
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
STARTING/CHARGING SYSTEM
VALVE COVER)
VALVETRONIC SERVOMOTOR (UNDER ENGINE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (1 of 5) -> BRN WIRE
