Supplemental restraints circuit, coupe for BMW 3 series E90/E91/E92/E93 facelift (2008-2013)

AIR BAG SIG - AIR BAG SIG + BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT POSITIONER CONTROLLER (LEFT REAR SIDE OF INTERIOR PANEL) DRIVER'S AIR BAG INFLATOR ASSEMBLIES DRIVER'S SWITCH CLUSTER FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE 30 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START JUNCTION FUSE 7 BOX (UNDER RIGHT SIDE OF DASH) LEFT "B" PILLAR AIR BAG SENSOR (LEFT REAR SIDE OF INTERIOR PANEL) LEFT FRONT AIR BAG SENSOR (LEFT SIDE OF ENGINE COMPT) LEFT SEAT BELT POSITIONER MOTOR (LEFT REAR SIDE INTERIOR PANEL) MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE ORG/ WIRE ORG/GRN WIRE PASSENGER AIR BAG DEACTIVATION SWITCH (RIGHT END OF DASH, NEAR RIGHT FRONT DOOR) RED WIRE RIGHT FRONT DOOR AIR BAG SENSOR (REAR OF RIGHT FRONT DOOR) RIGHT SEAT BELT POSITIONER MOTOR (RIGHT REAR SIDE INTERIOR PANEL) SIG CAN-BUS SIG CAN-BUS STEERING COLUMN SWITCH CLUSTER WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO/YEL WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CRASH SIG DIODE PANEL DRIVER'S SEAT BELT BUCKLE CONTACT DRV CASH - DRV CASH + PASS CASH + PASS CASH - LF DOOR + GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE OCCUPANCY SIG R B PILLAR SIG ORG/ WIRE ORG/GRN WIRE PASSENGER'S SEAT BELT BUCKLE CONTACT RED WIRE RIGHT "B" PILLAR AIR BAG SENSOR (RIGHT REAR SIDE OF INTERIOR PANEL) ROOF FUNCTION CONTROL CENTER SAFETY BATTERY TERMINAL GENERATOR SEAT OCCUPANCY RECOGNITION SHIELD TERMINAL R GROUND FRT PASS SIG L B PILLAR SENS TCU VIO WIRE VIO/BLU WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
