Driver power seat circuit for BMW 3 series E90/E91/E92/E93 facelift (2008-2013)
Driver power seat circuit
BACKREST
BRN WIRE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER SEAT)
DRIVER'S SIDE BACKREST ANGLE ADJUSTMENT MOTOR (UNDER DRIVER SEAT)
FUSE 45
FWD/BWD
GRN WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
RED WIRE
RELAY ENERGIZED
VIO WIRE
WHT WIRE
YEL WIRE
