BMW 3 series E90/E91/E92/E93 facelift (2008-2013) terminal 15 cond wel spd pt can high ground Wiring diagram

ACTIVE STEERING (IF EQUIPPED) (BEHIND LEFT FRONT WHEEL) BLU WIRE BLU/BRN/YEL WIRE BLU/RED WIRE BLU/VIO WIRE BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT) BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH) BRK FLD LVL RF WHL SPD BRN WIRE BRN/BLK WIRE BRN/GRN/YEL WIRE BRN/RED WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CC/M-ASK COMPUTER DATA LINES SYSTEM DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) EDC ELECTRONIC DAMPER CONTROL (RIGHT SIDE OF REAR COMPT) EXCEPT 3.0L TWIN TURBO DIESEL 3.0L TWIN TURBO DIESEL FUSE GRN/RED WIRE GROUND F-CAN-LOW HAZARD WARNING SWITCH HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT FRONT BRAKE PAD WEAR SENSOR (BEHIND LEFT FRONT WHEEL) LEFT REAR WHEEL SPEED SENSOR (BEHIND LEFT REAR WHEEL) NCA WIRE PARKING BRAKE WARNING SWITCH (UNDER CENTER CONSOLE) RED WIRE RED/ BLU WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RELAY ENERGIZED RF WHL SPD RR WHL SPD LR WHL SPD LF WHL SPD LF WHL SPD RIGHT REAR BRAKE PAD WEAR SENSOR (FRONT OF RIGHT REAR WHEEL) RIGHT REAR WHEEL SPEED SENSOR (BEHIND RIGHT REAR WHEEL) RR BRK PAD RR WHL SPD RR WHL SPP SEN GROUND STEERING COLUMN SWITCH CLUSTER STEERING GEAR (W/ ACTIVE STEERING) TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) TERMINAL 15 COND WEL SPD PT CAN HIGH GROUND TERMINAL 30 VIO/YEL WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
