BMW 3 series E90/E91/E92/E93 facelift (2008-2013) right side right side window window antenna antenna amplifier Wiring diagrams

This page contains all the electrical diagrams for the component. right side right side window window antenna antenna amplifier, in which he is found in the car BMW 3 series E90/E91/E92/E93 facelift (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right side right side window window antenna antenna amplifier (1 of 2)

Wiring diagram right side right side window window antenna antenna amplifier for BMW 3 series E90/E91/E92/E93 facelift (2008-2013) (1 of 2)

Get access

1 2 3 4 RIGHT SUB- WOOFER 2 3 1 4 LEFT SUB- WOOFER BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) FUSE 18 (UNDER RIGHT SIDE OF DASH) FUSE 19 GPS AERIAL GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SIDE LEFT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER MOST-BUS CONNECTOR NCA WIRE REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SIDE RIGHT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TUC/ULF-SBX ULF-SBX-H/ COM BOX W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/O COM BOX W/ COM BOX WAGON SEDAN, COUPE 2 3 4 WHT WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Base radio circuit, except convertible with cic (2 of 2) -> RIGHT SIDE RIGHT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER

Wiring diagram right side right side window window antenna antenna amplifier (2 of 2)

Wiring diagram right side right side window window antenna antenna amplifier for BMW 3 series E90/E91/E92/E93 facelift (2008-2013) (2 of 2)

Get access

1 2 3 4 RIGHT SUB- WOOFER 2 3 1 4 LEFT SUB- WOOFER BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) FUSE 18 (UNDER RIGHT SIDE OF DASH) FUSE 19 GPS AERIAL GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SIDE LEFT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER MOST-BUS CONNECTOR NCA WIRE REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SIDE RIGHT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TUC/ULF-SBX ULF-SBX-H/ COM BOX W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/O COM BOX W/ COM BOX WAGON SEDAN, COUPE 2 3 4 WHT WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, except convertible with base radio (2 of 2) -> RIGHT SIDE RIGHT SIDE WINDOW WINDOW ANTENNA ANTENNA AMPLIFIER
