BMW 3 series E90/E91/E92/E93 facelift (2008-2013) right front electronic wheel module Wiring diagram
This page shows the only wiring diagram for the component.right front electronic wheel module, which is found in the car BMW 3 series E90/E91/E92/E93 facelift (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front electronic wheel module (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 27
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
JUNCTION BOX
LEFT FRONT ELECTRONIC WHEEL MODULE
LEFT FRONT RDC TRANSMITTER
LEFT REAR ELECTRONIC WHEEL MODULE
LEFT REAR RDC TRANSMITTER
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RDC ANTENNA
RED WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT FRONT ELECTRONIC WHEEL MODULE
RIGHT FRONT RDC TRANSMITTER
RIGHT REAR ELECTRONIC WHEEL MODULE
RIGHT REAR RDC TRANSMITTER
TIRE PRESSURE CONTROL (RDC)
VIO WIRE
Go to component -> Warning systems circuit -> RIGHT FRONT ELECTRONIC WHEEL MODULE
