BMW 3 series E90/E91/E92/E93 facelift (2008-2013) rf dir ind sig parking light sig central locking sig Wiring diagram
This page shows the only wiring diagram for the component.rf dir ind sig parking light sig central locking sig, which is found in the car BMW 3 series E90/E91/E92/E93 facelift (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf dir ind sig parking light sig central locking sig (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRAKE/REAR FOG LIGHT
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/GRY/WHT WIRE
BRN/GRY/YEL WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
EXCEPT CONVERTIBLE
FOOTWELL MODULE
FUSE
GRN/YEL WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
HOT AT ALL TIMES
JUNCTION BOX
LF AUX DIR IND LIGHT LR DIR IND SIG UNLOCK CEN LOCKING SIG REVERSE LGHT SIG
LICENSE PLATE LIGHT PARKING LIGHT SIG
POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM HEADLIGHTS SYSTEM
POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RF DIR IND SIG PARKING LIGHT SIG CENTRAL LOCKING SIG
TERM 30 DRIV CLOSE PWR WIND MTR DRIV OPEN PWR WIND MTR HI BEAM SIG
VIO WIRE
VIO/BRN WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Body control modules circuit (2 of 2) -> RF DIR IND SIG PARKING LIGHT SIG CENTRAL LOCKING SIG
