BMW 3 series E90/E91/E92/E93 facelift (2008-2013) passenger's seat module Wiring diagram
This page shows the only wiring diagram for the component.passenger's seat module, which is found in the car BMW 3 series E90/E91/E92/E93 facelift (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's seat module (1 of 1)
BLU WIRE
BRN WIRE
CENTER CONSOLE SWITCH CENTER
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING ELEMENT (IN DRIVER SEAT BACK)
DRIVER'S SEAT CUSHION HEATING (IN DRIVER SEAT CUSHION)
DRIVERS SEAT MODULE (UNDER DRIVER SEAT)
ELECTRONICS JUNCTION BOX
FUSE 45 FUSE 46
GRN WIRE
HEATING/ AIR CONDITIONING
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
PASSENGER'S SEAT BACKREST HEATING ELEMENT (IN PASSENGER SEAT BACK)
PASSENGER'S SEAT CUSHION HEATING (IN PASSENGER SEAT CUSHION)
PASSENGER'S SEAT MODULE
RED WIRE
RED/BRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RELAY ENERGIZED FUSE 77
SYSTEM (CENTER OF DASH, ABOVE RADIO)
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Heated seats circuit, with memory -> PASSENGER'S SEAT MODULE
