BMW 3 series E90/E91/E92/E93 facelift (2008-2013) left rear hi-range speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left rear hi-range speaker, in which he is found in the car BMW 3 series E90/E91/E92/E93 facelift (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left rear hi-range speaker wiring diagram (1 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
FM AERIAL 1
FM AERIAL 2
FM AERIAL 3
FM AERIAL 4
FUSE 15
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SIDE TRIM PANEL MID-RANGE SPEAKER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HIGH RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, convertible with ccc & m-ask (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (2 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
FM AERIAL
FM AERIAL 1
FM AERIAL 2
FM AERIAL 4
FUSE 15
GRN WIRE
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SIDE TRIM PANEL MID-RANGE SPEAKER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER
RIGHT SUBWOOFER
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
SDARS AERIAL
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, convertible with cic (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (3 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
DUAL REMOTE CONTROL RECEIVER
FM AERIAL 1
FM AERIAL 2
FM AERIAL 3
FM AERIAL 4
FUSE 15
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SIDE TRIM PANEL MID-RANGE SPEAKER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, convertible without cic, ccc & m-ask (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (4 of 10)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE 15
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE WINDOW ANTENNA
LEFT SIDE WINDOW ANTENNA AMPLIFIER
LEFT SUBWOOFER
NCA WIRE
REAR SPOILER AM/FM AERIAL (WAGON)
REAR-WINDOW AERIAL
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SIDE WINDOW ANTENNA
RIGHT SIDE WINDOW ANTENNA AMPLIFIER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION
W/O AUTOMATIC ENGINE START-STOP FUNCTION WAGON SEDAN, COUPE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, except convertible with ccc & m-ask (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (5 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COUPE, SEDAN, WAGON
FUSE 15
GPS AERIAL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE WINDOW ANTENNA
LEFT SIDE WINDOW ANTENNA AMPLIFIER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW AERIAL (WAGON)
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SUBWOOFER
ROOF ANTENNA
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
VIDEO MODULE (LEFT SIDE OF REAR COMPT)
W/ AUTOMATIC ENGINE START-STOP FUNCTION
W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, except convertible with cic (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (6 of 10)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE 15
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SUBWOOFER
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WAGON
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, except convertible without cic, ccc & m-ask (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (7 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
FM AERIAL 1
FM AERIAL 2
FM AERIAL 3
FM AERIAL 4
FUSE 15
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SIDE TRIM PANEL MID-RANGE SPEAKER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HIGH RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, convertible with ccc, m-ask & hifi radio (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (8 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
FM AERIAL
FM AERIAL 1
FM AERIAL 2
FM AERIAL 4
FUSE 15
GRN WIRE
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SIDE TRIM PANEL MID-RANGE SPEAKER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER
RIGHT SUBWOOFER
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
SDARS AERIAL
W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, convertible with cic & hifi radio (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (9 of 10)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE 15
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE WINDOW ANTENNA
LEFT SIDE WINDOW ANTENNA AMPLIFIER
LEFT SUBWOOFER
NCA WIRE
REAR SPOILER AM/FM AERIAL (WAGON)
REAR-WINDOW AERIAL
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SIDE WINDOW ANTENNA
RIGHT SIDE WINDOW ANTENNA AMPLIFIER
RIGHT SUBWOOFER
W/ AUTOMATIC ENGINE START-STOP FUNCTION
W/O AUTOMATIC ENGINE START-STOP FUNCTION WAGON SEDAN, COUPE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, except convertible with ccc, m-ask & hifi radio (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
left rear hi-range speaker wiring diagram (10 of 10)
AERIAL DIVERSITY (CENTER REAR OF ROOF)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COUPE, SEDAN, WAGON
FUSE 15
GPS AERIAL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES HOT W/ TERMINAL
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT SIDE WINDOW ANTENNA
LEFT SIDE WINDOW ANTENNA AMPLIFIER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW AERIAL (WAGON)
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT SUBWOOFER
ROOF ANTENNA
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
VIDEO MODULE (LEFT SIDE OF REAR COMPT)
W/ AUTOMATIC ENGINE START-STOP FUNCTION
W/O AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, except convertible with cic & hifi radio (2 of 2) -> LEFT REAR HI-RANGE SPEAKER
