BMW 3 series E90/E91/E92/E93 facelift (2008-2013) leak diag sig sensor grd sensor grd sensor sig sensor sig Wiring diagram

ACC PDL GRD ACC PDL (+) ANTI-LOCK BRAKES SYSTEM ANTI-THEFT SYSTEM ANTI-THEFT SYSTEM STARTING/CHARGING SYSTEM BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE VACUUM SENSOR BRK SENS BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CRANKSHAFT BREATHER HEATING 1 (LEFT SIDE OF ENGINE) DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) E-BOX SIG FUSE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEAK DIAG SIG SENSOR GRD SENSOR GRD SENSOR SIG SENSOR SIG NCA WIRE ORG/ WIRE OXYGEN SENSOR 2 BEFORE CATALYTIC CONVERTER (RIGHT SIDE OF ENGINE) OXYGEN SENSOR 2 BEHIND CATALYTIC CONVERTER (RIGHT SIDE OF ENGINE) OXYGEN SENSOR BEFORE CATALYTIC CONVERTER (RIGHT SIDE OF ENGINE) OXYGEN SENSOR BEHIND CATALYTIC CONVERTER RADIATOR OUTLET TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE) RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY TERMINAL WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
