BMW 3 series E90/E91/E92/E93 (2005-2010) Navigation circuit, convertible with car information computer, hifi radio

1 2 (PIN 3-10 NOT USED) BISTABLE RELAY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM DIGITAL TUNER US ELECTRONICS JUCNTION BOX FUSE FUSE 18 FUSE 19 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) MOST-BUS CONNECTOR NCA WIRE ODBI SOCKET ON LEFT IN BUMPER TV ANTENNA ON RIGHT IN BUMPER TV ANTENNA ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE ROOF ANTENNA TCU USB PORT VIDEO MODULE (LEFT SIDE OF REAR COMPT) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AMPLIFIER (LEFT SIDE OF REAR COMPT) ANTENNA DIVERSITY BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CONVERTIBLE TOP MODULE FM ANTENNA 1 FM ANTENNA 2 FM ANTENNA 3 FM ANTENNA 4 FUSE 15 GRN WIRE GRY WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SIDE SECTION ANTENNA AMPLIFIER LEFT SUBWOOFER NCA WIRE REAR WINDOW ANTENNA AMPLIFIER REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SIDE SECTION ANTENNA AMPLIFIER RIGHT SUBWOOFER ROOF ANTENNA 2 SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
