Driver"s memory seat circuit, coupe for BMW 3 series E90/E91/E92/E93 (2005-2010)

BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT ADJUSTMENT SWITCH DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE (UNDER DRIVER'S SEAT) DRIVER'S SEAT BACKREST HEATING (IN DRIVER SEAT BACK) DRIVER'S SEAT CUSHION HEATING (IN DRIVER SEAT CUSHION) DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT) DRIVER'S SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER'S SIDE EASY ENTRY SWITCH FUSE GRN WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED FUSE VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

BLU WIRE BRN/VIO WIRE BRN/YEL WIRE CENTER CONSOLE SWITCH CENTER DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT) DRIVER'S SIDE BACKREST ANGLE ADJUSTMENT MOTOR (UNDER DRIVER'S SEAT) HEATING/AIR CONDITIONING SYSTEM NCA WIRE RED/YEL WIRE VIO WIRE VIO/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
