Instrument illumination circuit for BMW 3 series E90/E91/E92/E93 (2005-2010)

BLK WIRE BLK/VIO WIRE BRN WIRE BRN/BLK WIRE COUPE DRIVER SWITCH CLUSTER DRIVER'S DOOR COURTESY LIGHT FRONT CIGAR LIGHTER FRONT INTERIOR/ READING LAMP GEAR INDICATOR LIGHTING GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES FUSE 41 HOT AT ALL TIMES FUSE 81 HOT AT ALL TIMES FUSE 84 HOT AT ALL TIMES FUSE 86 JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LIGHT SWITCH UNIT NCA WIRE PASSENGER'S DOOR COURTESY LIGHT PASSENGER'S DOOR POWER WINDOW SWITCH RADIO REAR DRIVER'S SIDE COURTESY LIGHT (COUPE) REAR DRIVER'S SIDE POWER WINDOW SWITCH (SEDAN, WAGON) REAR LID RELEASE SWITCH (INTERIOR) REAR PASSENGER'S SIDE DOOR COURTESY LIGHT (COUPE) REAR PASSENGER'S SIDE POWER WINDOW SWITCH (SEDAN, WAGON) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE STEERING COLUMN SWITCH CLUSTER TELEPHONE RETROFIT PACKAGES CONNECTOR VIO WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
