BMW 3 series E90/E91/E92/E93 (2005-2010) wave trap Wiring diagrams
This page contains all the electrical diagrams for the component. wave trap, in which he is found in the car BMW 3 series E90/E91/E92/E93 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wave trap (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CONVERTIBLE WAGON COUPE 2 3
ELECTRONICS JUNCTION BOX
FUSE
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH, ABOVE RADIO)
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFROSTER
REAR WINDOW DEFROSTER (GROUND) LOCKOUT CIRCUIT
REAR WINDOW DEFROSTER (POSITIVE) LOCKOUT CIRCUIT
WAVE TRAP
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> WAVE TRAP
Wiring diagram wave trap (2 of 2)
B+ POTENTIAL DISTRIBUTOR
BLK WIRE
BLU WIRE
BRN WIRE
CAR ACCESS SYSTEM
DME CONTROL MODULE
DME RELAY
DRIVER'S SEAT HEATING MODULE
DYNAMIC STABILITY CONTROL (DSC)
ELECTRONICS JUNCTION BOX
EXCEPT CONVERTIBLE
FOOTWELL MODULE
FROM FUSE 63 (DIAGRAM 1 OF 5)
FROM FUSE 73 (DIAGRAM 2 OF 5)
FUSE
FUSE 35 FUSE 40
FUSE 41
FUSE 42
FUSE 44
FUSE 47
FUSE 51
FUSE 52
FUSE 53
FUSE 54
FUSE 79 FUSE 78 FUSE 80 FUSE 72 FUSE 73
FUSE FUSE 92 FUSE 88 FUSE 89
GRN WIRE
INSTRUMENT CLUSTER CONTROL MODULE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT REAR MICROWAVE SENSOR
OBDII SOCKET
REAR WINDOW DEFROSTER
REAR WINDOW DEFROSTER RELAY
RED WIRE
RED/BLK WIRE
ROLLOVER PROTECTION CONTROLLER
SIREN, TILT ALARM SENSOR
STEERING COLUMN SWITCH CLUSTER
TO FUSE
TO TERMINAL 15 RELAY (DIAGRAM 3 OF 5)
TRAILER MODULE
TRANSFER BOX CONTROL MODULE
VIO WIRE
W/ BOSCH
W/O BOSCH
W/O BOSCH W/ BOSCH
WAGON
WAVE TRAP
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> WAVE TRAP
