BMW 3 series E90/E91/E92/E93 (2005-2010) wagon, sedan coupe, convertible 3 2 Wiring diagram
This page shows the only wiring diagram for the component.wagon, sedan coupe, convertible 3 2, which is found in the car BMW 3 series E90/E91/E92/E93 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wagon, sedan coupe, convertible 3 2 (1 of 1)
2 2 5 COUPE WAGON, SEDAN CONVERTIBLE
BACKUP LIGHT SWITCH (M/T) (REAR OF TRANSMISSION)
BLK/BLU WIRE
BLK/VIO WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE WAGON, SEDAN COUPE
FOOTWELL MODULE (UNDER LEFT SIDE OF DASH)
FUSE
GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
REVERSE
RIGHT INNER TAILLIGHT (WAGON, SEDAN) RIGHT TAILLIGHT (COUPE, CONVERTIBLE)
WAGON SEDAN
WAGON, SEDAN COUPE, CONVERTIBLE 3 2
Go to component -> Backup lamps circuit -> WAGON, SEDAN COUPE, CONVERTIBLE 3 2
