BMW 3 series E90/E91/E92/E93 (2005-2010) vertical aim control motor Wiring diagrams

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPE, CONVERTIBLE WAGON, SEDAN EXCEPT CONVERTIBLE CONVERTIBLE FOG FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FOG LIGHT LEFT HEADLIGHT LEFT INNER TAILLIGHT ORG/GRN WIRE PARK RAIN/HEADLIGHT SENSOR (CENTER OF WINDSHIELD) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FOG LIGHT ROOF FUNCTION CONTROL CENTER TURN VERTICAL AIM CONTROL MOTOR WAGON COUPE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE YEL GRN/ WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COUPE, CONVERTIBLE WAGON, SEDAN FOG FRONT RIDE HEIGHT SENSOR (BEHIND LEFT FRONT WHEEL) GRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE LIGHT SWITCH UNIT PARK REAR RIDE HEIGHT SENSOR (FRONT OF RIGHT REAR WHEEL) RIGHT HEADLIGHT RIGHT INNER TAILLIGHT STEERING COLUMN SWITCH CLUSTER TURN VERTICAL AIM CONTROL MOTOR WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE
