BMW 3 series E90/E91/E92/E93 (2005-2010) towing roof function hitch release control centre Wiring diagram
This page shows the only wiring diagram for the component.towing roof function hitch release control centre, which is found in the car BMW 3 series E90/E91/E92/E93 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram towing roof function hitch release control centre (1 of 1)
ACTIVE DRIVER STEERING SEAT BELT POSITIONER CONTROLLER
AMPLIFIER RADIO
BLK WIRE
BLU WIRE
BRN WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
CONTROLLER
CONVERTIBLE TOP MODULE (CTM)
CUT-OUT RELAY, ELECTRIC FAN
DIGITAL TUNER US
DRIVER SEAT BELT POSITIONER CONTROLLER (COUPE)
DYNAMIC STABILITY CONTROL (DSC)
ELECTRONICS JUNCTION BOX
EXCEPT CONVERTIBLE
FROM FUSE 89 (DIAGRAM 2 OF 5)
FRONT PASSENGER SEAT BELT POSITIONER CONTROLLER
FRONT PASSENGER SEAT BELT POSITIONER CONTROLLER (COUPE)
FUSE 14
FUSE 15
FUSE 18
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 30
FUSE 45
FUSE 46
FUSE 49 FUSE 25
FUSE 77 FUSE 85
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRY WIRE
HEATING/AIR CONDITIONING SYSTEM
JUNCTION BOX
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
PASSENGER'S DRIVER'S SEAT SEAT MODULE MODULE
RED WIRE
RED/BLU WIRE
RIGHT LUGGAGE COMPARTMENT LIGHT
SATELLITE RECEIVER
SIDE-IN COMPARTMENT
STOP BUTTON
TERMINAL
TIRE PRESSURE CONTROL (RDC)
TO BISTABLE RELAY (DIAGRAM 5 OF 5)
TO DC/DC CONVERTER (DIAGRAM 5 OF 5)
TO FUSE 23 (DIAGRAM 5 OF 5)
TO FUSE 65 (DIAGRAM 4 OF 5)
TO TERMINAL 15 RELAY (DIAGRAM 4 OF 5)
TOWING ROOF FUNCTION HITCH RELEASE CONTROL CENTRE
TRANSFER BOX CONTROL MODULE (W/ AWD)
VIO WIRE
W/ HIFI W/ TOP HIFI
W/O AWD W/ AWD
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> TOWING ROOF FUNCTION HITCH RELEASE CONTROL CENTRE
