BMW 3 series E90/E91/E92/E93 (2005-2010) driver's door exit light passenger's side footwell light Wiring diagram

2 3 WAGON SEDAN, COUPE BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPE DRIVER'S DOOR COURTESY LIGHT DRIVER'S DOOR ENTRANCE LIGHT DRIVER'S DOOR EXIT LIGHT PASSENGER'S SIDE FOOTWELL LIGHT DRIVER'S SIDE FOOTWELL LIGHT FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FRONT INTERIOR/ READING LIGHT FUSE 41 FUSE 77 FUSE 84 FUSE 86 FUSE 81 GLOVE COMPARTMENT LIGHT GRN WIRE GRY WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT LUGGAGE COMPARTMENT LIGHT (WAGON) LIGHT SWITCH UNIT NCA WIRE ORG/GRN WIRE PASSENGER'S DOOR COURTESY LIGHT PASSENGER'S DOOR ENTRANCE LIGHT PASSENGER'S DOOR EXIT LIGHT REAR DRIVER'S SIDE DOOR COURTESY LIGHT REAR DRIVER'S SIDE DOOR LIGHT (WAGON, SEDAN) REAR INTERIOR LIGHT REAR PASSENGER'S SIDE DOOR COURTESY LIGHT REAR PASSENGER'S SIDE DOOR ENTRANCE LIGHT (WAGON, SEDAN) REAR WINDOW LOCK (WAGON) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT LUGGAGE COMPARTMENT LIGHT TOWING HITCH RELEASE TRUNK LID CENTRAL LOCKING DRIVE (ON REAR COMPT DOOR) TRUNK LID/ TAILGATE LUGGAGE COMPARTMENT LIGHT (WAGON) VIO WIRE VIO/BRN WIRE WAGON WHT WIRE YEL WIRE
