BMW 3 series E90/E91/E92/E93 (2005-2010) convertible wagon Wiring diagram
This page shows the only wiring diagram for the component.convertible wagon, which is found in the car BMW 3 series E90/E91/E92/E93 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible wagon (1 of 1)
AMPLIFIER
AUC SENSOR
AUXILIARY BRAKE LIGHT
BRN WIRE
BRN/BLK WIRE
CD DIGITAL CHANGER TUNER US
COMFORT ACCESS CONTROL MODULE
CONVERTIBLE WAGON
COUPE CONVERTIBLE WAGON 2 5 1
COUPE WAGON 2 3
COUPE, WAGON TIRE PRESSURE CONTROL RIGHT (RDC) TAIL LIGHT
EJECT BOX
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE
FUEL PUMP CONTROL (EKPS)
GEAR INDICATOR LIGHTING
LEFT RIGHT LICENSE LICENSE PLATE PLATE LIGHT LIGHT
NCA WIRE
PARK DISTANCE CONTROL (PDC)
REAR PASSENGER'S SIDE POWER WINDOW SWITCH
REAR PASSENGER'S SIDE SYSTEM LOCK
REAR WINDOW DUAL REMOTE DEFROSTER CONTROL RECEIVER
RIGHT HEADLIGHT
RIGHT INNER TAIL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR MICROWAVE SENSOR
RIGHT RELEASE ROLLER COVER MOTOR
SATELLITE RECEIVER
STEPTRONIC SWITCH
TCU
TOWING TOWING HITCH HITCH RELEASE RELEASE DRIVE UNIT
TRAILER SOCKET
TRUNK LID BUTTON
TRUNK LID LEFT CENTRAL INNER LOCKING TAIL DRIVE LIGHT
USB- HUB
VIDEO MODULE
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (3 of 4) -> CONVERTIBLE WAGON
