BMW 3 series E90/E91/E92/E93 (2005-2010) auxiliary heated switchover valve wiring diagram
This page shows the only wiring diagram for the component.auxiliary heated switchover valve, which is found in the car BMW 3 series E90/E91/E92/E93 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
auxiliary heated switchover valve wiring diagram (1 of 1)
3.0L
3.0L TWIN TURBO
AUXILIARY HEATED SWITCHOVER VALVE
BLK WIRE
BRN WIRE
BRN/RED WIRE
ELECTRONICS JUNCTION BOX
FUSE
HEATER
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH, ABOVE RADIO)
INDEPENDENT AUXILIARY HEATER CONTROL MODULE (LEFT SIDE OF FRONT BUMPER)
METERING PUMP (UNDER VEHICLE)
NCA WIRE
RED/GRN WIRE
RED/GRY WIRE
RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
WHT/BLU WIRE
YEL/BRN WIRE
Go to component -> Independent heating circuit -> AUXILIARY HEATED SWITCHOVER VALVE
