BMW 3 series E46 facelift (2001-2006) passenger's backrest heater passenger's backrest heater Wiring diagram
This page shows the only wiring diagram for the component.passenger's backrest heater passenger's backrest heater, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's backrest heater passenger's backrest heater (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER'S BACKREST HEATER
DRIVER'S SEAT HEATER
FUSE
FUSE HOLDER (GLOVE BOX)
GRN/VIO WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN START, RUN OR ACC
INSTRUMENT CLUSTER CONTROL MODULE
PASSENGER'S BACKREST HEATER PASSENGER'S BACKREST HEATER
RED WIRE
RED/VIO WIRE
SWITCH CENTER
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED/YEL WIRE
YEL WIRE
Go to component -> Heated seats circuit -> PASSENGER'S BACKREST HEATER PASSENGER'S BACKREST HEATER
