BMW 3 series E46 facelift (2001-2006) mirror adjustment switch Wiring diagrams
This page contains all the electrical diagrams for the component. mirror adjustment switch, in which he is found in the car BMW 3 series E46 facelift (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror adjustment switch (1 of 4)
5 47 (OTHERS)
ABS/ASC UNIT OR ABS/DSC UNIT
BEHIND BRAKE BOOSTER)
BRN WIRE
DRIVER'S DOOR POWER WINDOW MOTOR (CONVERTIBLE)
DRIVER'S DRIVER'S BACKREST SEAT HEATING HEATING
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT MEMORY CONTROL UNIT
DRIVER'S SIDE FOOTWELL, RIGHT
DRIVER'S SIDE OUTSIDE MIRROR WITH MEMORY
DRIVER'S SIDE PRESSURE, SENSITIVE FINGER GUARD
E-BOX PRECHARGE FAN PUMP
EAC SENSOR
ELECTRIC FAN
EXCEPT CONVERTIBLE
FRONT LEFT AUXILIARY FLASHER UNIT
FRONT RIGHT TURN SIGNAL LAMP
HEADLIGHT WASHER PUMP
LUMBAR SUPPORT ONLY
MIRROR ADJUSTMENT SWITCH
MIRROR CONTROL UNIT, DRIVER'S SIDE
NCA WIRE
RIGHT FOG LIGHT
RIGHT HIGH BEAM
RIGHT HORN
RIGHT LOW BEAM
RIGHT PARKING LIGHT
RIGHT REAR ENG COMPT,
SECONDARY AIR INJECTION PUMP
SECONDARY AIR INJECTION PUMP RELAY
SEDAN, WAGON, 2004-2006 CONVERTIBLE COUPE W/ MEMORY
SIDE MARKER LIGHT, LEFT
SYSTEM LOCK, DRIVER'S DOOR
VALVE BLOCK DRIVER'S LUMBAR SUPPORT
W/ DSC
W/ MEMORY
W/ SEAT MEMORY
W/ XENON HEADLIGHT
W/O MEMORY
W/O SEAT MEMORY
W/O SMF MEMORY SEAT, DRIVER
W/O XENON HEADLIGHT
WASHER PUMP
WIPER CHIME MOTOR MODULE
WIPER RELAY
XENON HEADLIGHT, RIGHT
Go to component -> Ground distribution circuit (2 of 4) -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (2 of 4)
1 2 3 ADJUST SW ADJUST SW ADJUST SW
1 2 3 DATA TERM 30 TERM 31
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT MEMORY CONTROL UNIT
DRIVER'S SIDE MEMORY MIRROR
FOLDING MOTOR
FUSE
FUSE HOLDER (GLOVE BOX)
GENERAL MODULE CONTROL UNIT
HEATING ELEMENT
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
MIRROR ADJUSTMENT SWITCH
PASSENGER'S SIDE MEMORY MIRROR
POSITION MOTORS
POSITION SENSORS
RED/GRN/YEL WIRE
SET SWITCH PROGRAM SWITCHES (3)
WHT/RED/YEL WIRE
Go to component -> Memory mirrors circuit -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (3 of 4)
A/T
ABS/ASC UNIT
ADAPTIVE SWITCH CENTER HEADLIGHT CONTROL UNIT (IF EQUIPPED)
AUXILIARY WATER PUMP
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
DIGITAL MOTOR OIL LEVEL ELECTRONICS SENSOR CONTROL UNIT
DUAL FUNCTION SWITCH RECIRCULATED AIR/REAR WINDOW DEFOGGER
ELECTROCHROMIC PARK INTERIOR REAR DISTANCE VIEW MIRROR CONTROL UNIT
ELECTRONIC IMMOBLIZER CONTROL UNIT
FROM
FROM FUSE
FUSE
FUSE (DIAGRAM 5 OF 6)
FUSE FUSE
FUSE HOLDER (GLOVE BOX)
GARAGE REVERSING DOOR LIGHT OPENER RELAY
GENERATOR
GRN WIRE
HEATED SPRAY NOZZLES THERMAL SWITCH
HEATING, A/C CONTROL MODULE
IGNITION SWITCH
INSTRUMENT CLUSTER CONTROL MODULE
KEY-IN SWITCH
M/T
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OBD SOCKET
OFF
PASSENGER'S SIDE OUTSIDE MIRROR
PROGRAM BUTTON
REAR WINDOW DEFOGGER RELAY (CONVERTIBLE)
RED WIRE
REVERSING LIGHT SWITCH
RUN WIRE
STEERING ANGLE SENSOR (W/O AWD) ABS/DSC UNIT
SWITCH CENTER
TEMPERATURE SWITCH
TIRE LIGHT SWITCHING PRESSURE CENTER CONTROL CONTROL SYSTEM UNIT CONTROL UNIT
TO FUSE
TRANSMISSION CONTROL UNIT
VIO WIRE
W/ ASC
W/ DSC
W/ HEATER CONTROL
W/O HEATER CONTROL
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> MIRROR ADJUSTMENT SWITCH
Wiring diagram mirror adjustment switch (4 of 4)
Go to component -> Power mirrors circuit -> MIRROR ADJUSTMENT SWITCH
