BMW 3 series E46 facelift (2001-2006) licence plate lights 1) push button, open tailgate Wiring diagram
This page shows the only wiring diagram for the component.licence plate lights 1) push button, open tailgate, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram licence plate lights 1) push button, open tailgate (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/WHT WIRE
CENTRAL LOCKING DRIVE, TRUNK LID/TAILGATE (REAR LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
FUSE HOLDER (GLOVE BOX)
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HAZARD WARNING/ CENTRAL LOCKING SWITCH
HOT AT ALL TIMES FUSE
INTERMITTENT WIPE/WASH CONTROL UNIT (REAR) (LIFT GATE)
LICENCE PLATE LIGHTS 1) PUSH BUTTON, OPEN TAILGATE
NCA WIRE
REAR WINDOW DRIVE RELAY (RIGHT FOOTWELL)
REAR WINDOW OPENING SWITCH 1) REAR WINDOW OPENING DRIVE
RED WIRE
SYSTEM LOCK, REAR DRIVER'S DOOR
SYSTEM LOCK, REAR PASSENGER'S DOOR
TRUNK LID RELEASE SOLENOID SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, wagon (2 of 2) -> LICENCE PLATE LIGHTS 1) PUSH BUTTON, OPEN TAILGATE
