BMW 3 series E46 facelift (2001-2006) left sub- woofer speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left sub- woofer speaker, in which he is found in the car BMW 3 series E46 facelift (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left sub- woofer speaker (1 of 2)
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
COUPE CONVERTIBLE
COUPE, SEDAN
GRN WIRE
L SUB
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT MID-RANGE, TWEETER SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR HIGH RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR SPEAKER
LEFT REAR WOOFER SPEAKER
LEFT SUB- WOOFER SPEAKER
LR AF+ LF AF+ LF MR- LF MR+ RF MR- RF MR+
LR AF- LF AF- LR R+ LR R- LFT+ LFT-
NCA WIRE
R SUB
REAR SUBWOOFER BOX
RED/GRN WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT MID-RANGE, TWEETER SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT FRONT WOOFER SPEAKER LEFT FRONT WOOFER SPEAKER
RIGHT REAR HIGH RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR SPEAKER
RIGHT REAR WOOFER SPEAKER
RIGHT SUB- WOOFER SPEAKER
SEDAN
SPD SIG
SPD SIG SPD SIG RR R- RFW- RFW+ RR- RR+ 31
SUBWOOFER BOX (EXCEPT CONVERTIBLE)
SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, with top hifi radio with monitor (2 of 2) -> LEFT SUB- WOOFER SPEAKER
Wiring diagram left sub- woofer speaker (2 of 2)
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
COUPE CONVERTIBLE
COUPE, SEDAN
GRN WIRE
L SUB
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT MID-RANGE, TWEETER SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR HIGH RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR SPEAKER
LEFT REAR WOOFER SPEAKER
LEFT SUB- WOOFER SPEAKER
LR AF+ LF AF+ LF MR- LF MR+ RF MR- RF MR+
LR AF- LF AF- LR R+ LR R- LFT+ LFT-
NCA WIRE
R SUB
REAR SUBWOOFER BOX
RED/GRN WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT MID-RANGE, TWEETER SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT FRONT WOOFER SPEAKER LEFT FRONT WOOFER SPEAKER
RIGHT REAR HIGH RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR SPEAKER
RIGHT REAR WOOFER SPEAKER
RIGHT SUB- WOOFER SPEAKER
SEDAN
SPD SIG
SPD SIG SPD SIG RR R- RFW- RFW+ RR- RR+ 31
SUBWOOFER BOX (EXCEPT CONVERTIBLE)
SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, with top hifi radio without monitor (2 of 2) -> LEFT SUB- WOOFER SPEAKER
