BMW 3 series E46 facelift (2001-2006) idle speed control valve Wiring diagrams

This page contains all the electrical diagrams for the component. idle speed control valve, in which he is found in the car BMW 3 series E46 facelift (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram idle speed control valve (1 of 3)

Wiring diagram idle speed control valve for BMW 3 series E46 facelift (2001-2006) (1 of 3)

Get access

ANTI-THEFT ALARM SYSTEM HORN BLK WIRE BRN WIRE CD CHANGER COUPE DIGITAL MOTOR ELECTRONICS CONTROL UNIT ELECTRO- CHROMIC INTERIOR REAR-VIEW MIRROR ELECTRONIC IMMOBILIZER CONTROL UNIT EVAPORATIVE EMISSION VALVE FROM FRONT PASSENGER'S SEAT ADJUSTMENT SWITCH FRONT PASSENGER'S SEAT CONTROL MEMORY UNIT FUSE FUSE HOLDER (GLOVE BOX) GRN WIRE HIFI SUB- AMPLIFIER WOOFER (IF (IF EQUIPPED) EQUIPPED) IDLE SPEED CONTROL VALVE INDIVIDUAL CONTROL INTAKE SYSTEM VALVE INTERIOR PROTECTION 1 CONTROL MODULE INTERIOR PROTECTION 2 CONTROL MODULE (CONVERTIBLE) NAVIGATION GPS COMPUTER RECEIVER (IF EQUIPPED) NCA WIRE ON-BOARD MONITOR CONTROL UNIT (IF EQUIPPED) PASSENGER'S FRONT LUMBAR PASSENGER'S SUPPORT SEAT SWITCH CONTROL MEMORY UNIT PASSENGER'S LUMBAR SUPPORT SWITCH RADIO CONTROL UNIT REAR WINDOW DEFOGGER RELAY RED WIRE SECONDARY AIR INJECTION PUMP VALVE SEDAN OR WAGON W/ MEMORY SEDAN OR WAGON W/O MEMORY TILT MONITORING TIRE PRESSURE CONTROL SYSTEM CONTROL UNIT TO FUSE VANOS VANOS OUTLET INLET VALVE VALVE WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (4 of 6) -> IDLE SPEED CONTROL VALVE

Wiring diagram idle speed control valve (2 of 3)

Wiring diagram idle speed control valve for BMW 3 series E46 facelift (2001-2006) (2 of 3)

Get access

B+ POTENTIAL DISTRIBUTOR BLK WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRAKE LIGHT SWITCH (NEAR STEERING COLUMN) BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/WHT WIRE CLUTCH SWITCH MODULE (M/T) (CLUTCH PEDAL) COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT REAR OF ENGINE COMPT) DME RELAY E BOX (LEFT REAR OF ENGINE COMPT) FUSE E-BOX (LEFT REAR OF ENGINE COMPT) FUSE FUSE FUSE GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRY WIRE HEATED OXYGEN SENSOR 2 IN FRONT OF CATALYTIC CONVERTER HEATED VANOS OXYGEN OUTLET SENSOR 2 VALVE BEHIND CATALYTIC CONVERTER HOT AT ALL TIMES HOT IN ACCY, RUN OR START FUSE HOLDER (GLOVE BOX) FUSE IDLE SPEED CONTROL VALVE INDIVIDUAL CONTROL INTAKE SYSTEM VALVE N/A NCA WIRE ORG/ WIRE RED WIRE RED/WHT WIRE RED/WHT/YEL WIRE SECONDARY AIR INJECTION PUMP VALVE VANOS EVAPORATIVE INLET EMISSION VALVE VALVE VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Wiring diagram engine performance 2.5l, sulev (2 of 3) -> IDLE SPEED CONTROL VALVE
