BMW 3 series E46 facelift (2001-2006) gear indicator steptronic light switch Wiring diagram
This page shows the only wiring diagram for the component.gear indicator steptronic light switch, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gear indicator steptronic light switch (1 of 1)
AMPLIFIER
BASIC INTERFACE TELEPHONE
BRAKE FLUID WINDSCREEN LEVEL WIPER SWITCH SWITCH
BRN WIRE
BRN/BLK WIRE
CD CHANGER
CENTRAL LOCKING DRIVE, TRUNK LID/ TAILGATE
CLUTCH SWITCH MODULE
CONTROL MODULE FOR ADAPTIVE HEADLIGHT
CONVER- TIBLE ONLY
CONVERTIBLE TOP ONLY
COUPE
COUPE, SEDAN ONLY
DRIVER, CONVERTIBLE TOP COVER
EJECT BOX COMPENSATOR
ELECTRONIC IMMOBILIZER CONTROL UNIT
ENGINE COOLANT LEVEL SWITCH
GEAR INDICATOR STEPTRONIC LIGHT SWITCH
HAZARD WARNING/ CENTRAL LOCKING SWITCH
IGNITION COIL 6
IGNITION IGNITION COIL 4 COIL 5
IGNITION IGNITION IGNITION COIL 1 COIL 2 COIL 3
INSTRUMENT CLUSTER CONTROL MODULE
INTERMITTENT WIPER/WASHER CONTROL UNIT, REAR
LICENSE PLATE LIGHTS
LIFT GATE LOCK SWITCH
LIGHT SWITCHING CENTER FOG WASHER CONTROL LIGHT FLUID LEVEL UNIT RELAY SWITCH
MANUAL CONVERTIBLE TOP ONLY
MAYDAY SWITCH
MOTOROLA CELLULAR PHONE
NAVIGATION COMPUTER
NCA WIRE
ON-BOARD MONITOR CONTROL UNIT
PARK DISTANCE CONTROL RAIN UNIT SENSOR
PRESSURE TIRE CONTROL CONTROL MODULE, TIRE SYSTEM FAILURE CONTROL UNIT INDICATOR
RADIO CONTROL UNIT
RDW RDC
REAR WASHER PUMP
REAR WINDOW OPENING SWITCH
SEDAN
SIEMENS FIXED MOUNTING
SUB WOOFER BOX
SWITCH BLOCK, SELECTOR REAR DRIVER'S LEVER ASHTRAY DOOR ASG LIGHT
SWITCH CONVERTIBLE TOP COVER LOCKED, RIGHT
SWITCH, CONVERTIBLE TOP COMPART- MENT FLOOR
SWITCH, CONVERTIBLE TOP COVER DRIVE
SWITCH, CONVERTIBLE TOP COVER LOCKED, LEFT
TAILLIGHT, RIGHT
TELEMATIC CONTROL UNIT
TELEMATICS CONTROL MODULE
TRAILER MODULE
TRAILER SOCKET
TRANSCEIVER/ CHARGING ELECTRONICS
TRUNK LID LAMP, LEFT
TRUNK LID LAMP, RIGHT
TRUNK LID STEERING RELEASE ANGLE SWITCH SENSOR (INTERIOR)
UNDERHOOD GENERAL LIGHT MODULE SWITCH CONTROL SWITCHING UNIT CENTER
UNIVERSAL CHARGING, HANDS-FREE FACILITY
UNIVERSAL ELECTRONIC CHARGING, HANDS-FREE MODULE
VIDEO MODULE CONTROL UNIT
VOICE EJECT ANTENNA INPUT BOX SPLITTER
VOICE EJECT INPUT BOX
VOLUTE CONTROL SPRING MODULE, INTERIOR PROTECTION I
W/ BM ON-BOARD MONITOR
W/ SMG
WAGON
WAGON ONLY
XENON HEADLIGHT, LEFT
XENON HEADLIGHT, RIGHT
Go to component -> Ground distribution circuit (4 of 4) -> GEAR INDICATOR STEPTRONIC LIGHT SWITCH
