BMW 3 series E46 facelift (2001-2006) front passenger's seat adjustment switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat adjustment switch, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's seat adjustment switch (1 of 1)
ANTI-THEFT ALARM SYSTEM HORN
BLK WIRE
BRN WIRE
CD CHANGER
COUPE
DIGITAL MOTOR ELECTRONICS CONTROL UNIT
ELECTRO- CHROMIC INTERIOR REAR-VIEW MIRROR
ELECTRONIC IMMOBILIZER CONTROL UNIT
EVAPORATIVE EMISSION VALVE
FROM
FRONT PASSENGER'S SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT CONTROL MEMORY UNIT
FUSE
FUSE HOLDER (GLOVE BOX)
GRN WIRE
HIFI SUB- AMPLIFIER WOOFER (IF (IF EQUIPPED) EQUIPPED)
IDLE SPEED CONTROL VALVE
INDIVIDUAL CONTROL INTAKE SYSTEM VALVE
INTERIOR PROTECTION 1 CONTROL MODULE
INTERIOR PROTECTION 2 CONTROL MODULE (CONVERTIBLE)
NAVIGATION GPS COMPUTER RECEIVER (IF EQUIPPED)
NCA WIRE
ON-BOARD MONITOR CONTROL UNIT (IF EQUIPPED)
PASSENGER'S FRONT LUMBAR PASSENGER'S SUPPORT SEAT SWITCH CONTROL MEMORY UNIT
PASSENGER'S LUMBAR SUPPORT SWITCH
RADIO CONTROL UNIT
REAR WINDOW DEFOGGER RELAY
RED WIRE
SECONDARY AIR INJECTION PUMP VALVE
SEDAN OR WAGON W/ MEMORY
SEDAN OR WAGON W/O MEMORY
TILT MONITORING
TIRE PRESSURE CONTROL SYSTEM CONTROL UNIT
TO FUSE
VANOS VANOS OUTLET INLET VALVE VALVE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 6) -> FRONT PASSENGER'S SEAT ADJUSTMENT SWITCH
