BMW 3 series E46 facelift (2001-2006) front dn Wiring diagram
This page shows the only wiring diagram for the component.front dn, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front dn (1 of 1)
BACK
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
CUSHION TILT
DN UP
DN UP BACK FRONT
DRIVER'S BACKREST ADJUSTMENT MOTOR
DRIVER'S FORWARD/ BACKWARD ADJUSTMENT MOTOR
DRIVER'S HEIGHT ADJUSTMENT MOTOR
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S TILT ADJUSTMENT MOTOR
FRONT
FRONT BACK
FRONT DN
FUSE
FUSE HOLDER (GLOVE BOX)
FWD/BWD
GRN WIRE
GRY WIRE
HEIGHT
HOT AT ALL TIMES
LUMBAR CIRCUIT (IF EQUIPPED)
NCA WIRE
PASSENGER'S BACKREST ADJUSTMENT MOTOR
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S TILT ADJUSTMENT MOTOR
RED WIRE
UP DN
VIO WIRE
YEL WIRE
