BMW 3 series E46 facelift (2001-2006) convertible soft top closed push button Wiring diagram
This page shows the only wiring diagram for the component.convertible soft top closed push button, which is found in the car BMW 3 series E46 facelift (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible soft top closed push button (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONVERTIBLE SOFT TOP CLOSED PUSH BUTTON
CONVERTIBLE TOP REAR WINDOW DEFROSTER
FUSE
FUSE HOLDER (GLOVE BOX)
GRN WIRE
HEATING, A/C CONTROL MODULE
HOT AT ALL TIMES
HOT IN ACC, RUN OR START
HOT IN RUN OR START
REAR DEFROSTER RELAY (RIGHT REAR PASSENGER COMPT)
REAR WINDOW DEFROSTER RELAY (RIGHT REAR PASSENGER COMPT)
RED WIRE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit, convertible without cvm -> CONVERTIBLE SOFT TOP CLOSED PUSH BUTTON
