BMW 3 series E46 (1998-2003) w/ infrared remote control w/ radio remote control Wiring diagram
This page shows the only wiring diagram for the component.w/ infrared remote control w/ radio remote control, which is found in the car BMW 3 series E46 (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ infrared remote control w/ radio remote control (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/GRY/YEL WIRE
BRN/RED WIRE
CENTRAL LOCKING DRIVE FUEL FILTER FLAP (RIGHT SIDE OF LUGGAGE COMPT)
CENTRAL LOCKING REMOTE CONTROL
ELECTRONIC INTERIOR REAR-VIEW MIRROR
FUSE HOLDER (GLOVE BOX)
GENERAL MODULE CONTROL UNIT (BEHIND GLOVE BOX)
GRY/BLK/YEL WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE
N/A
N/A 9 15
NCA WIRE
RED WIRE
RED/BLK WIRE
SYSTEM LOCK, DRIVER'S DOOR
SYSTEM LOCK, PASSENGER'S DOOR
VIO WIRE
W/ INFRARED REMOTE CONTROL W/ RADIO REMOTE CONTROL
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED/YEL WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, wagon (1 of 2) -> W/ INFRARED REMOTE CONTROL W/ RADIO REMOTE CONTROL
