BMW 3 series E46 (1998-2003) spatial sound switch Wiring diagrams

ANTENNA AMPLIFIER ANTENNA AMPLIFIER W/ ROD ANTENNA BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CD CHANGER CELLULAR PHONE (W/ VOICE INPUT) COUPE, SEDAN (LEFT SIDE OF RIGHT FOOTWELL) EXCEPT CONVERTIBLE FUSE FUSE HOLDER (GLOVE BOX) GRN WIRE HOT AT ALL TIMES HOT IN RUN, ACC OR START INSTRUMENT CLUSTER CONTROL MODULE ON-BOARD MONITOR CONTROL MODULE K- BUS NAVIGATION COMPUTER (IF EQUIPPED) NCA WIRE RADIO CONTROL UNIT REAR DEFROSTER RELAY REAR WINDOW RED WIRE RED/GRN WIRE SPATIAL SOUND SWITCH SPEED SWITCH CENTER TELEPHONE PROVISION VIDEO MODULE CONTROL UNIT (IF EQUIPPED) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

ANTENNA AMPLIFIER ANTENNA AMPLIFIER W/ ROD ANTENNA BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CD CHANGER COUPE, SEDAN (LEFT SIDE OF RIGHT FOOTWELL) EXCEPT CONVERTIBLE FUSE FUSE HOLDER (GLOVE BOX) GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACC OR START INSTRUMENT CLUSTER CONTROL MODULE INTERIOR LIGHTS K- BUS NAVIGATION COMPUTER (IF EQUIPPED) NCA WIRE RADIO CONTROL UNIT REAR DEFROSTER RELAY REAR WINDOW RED WIRE RED/GRN WIRE SPATIAL SOUND SWITCH SPEED SWITCH CENTER TELEPHONE PROVISION VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
