BMW 3 series E46 (1998-2003) rollover sensor Wiring diagram
This page shows the only wiring diagram for the component.rollover sensor, which is found in the car BMW 3 series E46 (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rollover sensor (1 of 1)
ANTENNA AMPLIFIER (IF EQUIPPED)
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
CLUTCH SWITCH MODULE
CONVERTIBLE SOFT TOP CLOSED PUSHBUTTON (IF EQUIPPED)
CONVERTIBLE SOFT TOP CONTROL MODULE
DRIVER'S SEAT BELT BUCKLE HALL SENSOR
DRIVER'S SIDE MAKE-UP MIRROR LIGHT
ELECTRONIC IMMOBILIZER CONTROL UNIT
FROM
FROM IGNITION SWITCH (DIAGRAM 5 OF 6)
FUSE
FUSE FUSE
FUSE HOLDER (GLOVE BOX)
GEARSHIFT LOCK
GENERAL MODULE CONTROL UNIT
GPS RECEIVER (IF EQUIPPED)
GRN WIRE
GRY WIRE
HORN RELAY
INSTRUMENT CLUSTER CONTROL MODULE
LEFT SIDE AIRBAG SENSOR (SATELLITE) (IF EQUIPPED)
LIGHT SWITCHING CENTER CONTROL UNIT
MULTIPLE RESTRAINT SYSTEM CONTROL UNIT
NCA WIRE
ON-BOARD MONITOR CONTROL UNIT (IF EQUIPPED)
PASSENGER'S SEAT BELT BUCKLE HALL SENSOR
PASSENGER'S SIDE MAKE-UP MIRROR LIGHT
RADIO CONTROL UNIT
RAIN SENSOR
REAR INTERMITTENT WIPE/WASH CONTROL UNIT (WAGON)
RIGHT SIDE AIRBAG SENSOR (SATELLITE) (IF EQUIPPED)
ROLLOVER SENSOR
SEAT LOAD SENSOR
SWITCH CENTER
TO FUSE
VIO WIRE
VOLUTE SPRING
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> ROLLOVER SENSOR
