BMW 3 series E46 (1998-2003) glovebox trunklid disable switch Wiring diagram
This page shows the only wiring diagram for the component.glovebox trunklid disable switch, which is found in the car BMW 3 series E46 (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glovebox trunklid disable switch (1 of 1)
BLK WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CENTRAL LOCKING DRIVE, TRUNK LID/TAILGATE (REAR LUGGAGE COMPT)
CENTRAL LOCKING REMOTE CONTROL
ELECTRONIC INTERIOR REAR-VIEW MIRROR
FUSE
GENERAL MODULE CONTROL UNIT (BEHIND GLOVE BOX)
GLOVEBOX TRUNKLID DISABLE SWITCH
GRY/BLK/YEL WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER (GLOVE BOX) FUSE
N/A 9 15
NCA WIRE
RED WIRE
RED/BLK WIRE
TRUNK LID RELEASE SWITCH (INTERIOR)
VIO WIRE
W/ INFRARED REMOTE CONTROL
W/ RADIO REMOTE CONTROL
WHT/BRN WIRE
Go to component -> Trunk, tailgate, fuel door circuit, convertible -> GLOVEBOX TRUNKLID DISABLE SWITCH
