A/c circuit for BMW 3 series E36 (1990-2000)

4-CYL 4-CYL 6-CYL 4-CYL ONLY 6- CYL 6-CYL 4-CYL : W/O PARK VENTILATION : W/PARK VENTILATION AIR CONDITIONING COMPRESSOR AUTOMATIC CLIMATE CONTROL MODULE (BEHIND CENTER CONSOLE) AUXILIARY FAN MOTOR (4-CYL) AUXILIARY FAN MOTOR (6-CYL) AUXILIARY FUSE BOX (LEFT SIDE OF DASH BEHIND INSTRUMENT CLUSTER) BLK WIRE BLK/ BLU WIRE BLK/ WHT/ YEL WIRE BLK/BLU WIRE BLK/BRN (OR BLK/GRY) WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED/YEL WIRE BLK/WHT WIRE BLK/WHT/YEL WIRE BLOWER MOTOR (REAR OF ENGINE COMPARTMENT) BLOWER RELAY (IN POWER DISTRIBUTION BOX) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE BRN/YEL WIRE COMPRESSOR CONTROL RELAY (IN POWER DIST BOX) DATA LINK CONNECTOR (RIGHT REAR SIDE OF ENGINE COMPARTMENT) DEFOGGER, POWER ANTENNA SYSTEMS DEFROSTER FLAP MOTOR DOUBLE TEMPERATURE SWITCH TEMPERATURE SWITCH (4 CYL) (6 CYL) ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) FINAL STAGE UNIT (BEHIND LEFT SIDE OF DASH) FRESH AIR FLAP MOTOR (BELOW LEFT SIDE OF DASH, RIGHT OF IKHA PLENUM) FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT) FUSE 16 FUSE 20 FUSE 23 FUSE 31 FUSE 39 FUSE 41 FUSE 48 GRN BRN/ WIRE GRN WIRE GRN/ BLU WIRE GRN/ YEL WIRE GRN/BLU WIRE GRN/BRN (OR RED/GRN) WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN RUN, START IGNITION SWITCH INSTRUMENT CLUSTER LEFT HEAT EXCHANGER TEMP SENSOR (CENTER CONSOLE) LEFT VALVE NCA WIRE NORMAL SPEED RELAY (IN POWER DIST BOX) OFF ORG/ WIRE PARK VENTILATION CIRCUIT PRESSURE SWITCH RECIRCULATION FLAP MOTOR RED WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE REGULATION FLAP MOTOR REAR RECIRCULATION FLAP MOTOR RIGHT HEAT EXCHANGER TEMP SENSOR (CENTER CONSOLE) RIGHT VALVE RUN WIRE STARTING/ CHARGING SYSTEM TRANSMISIION CONTROLS SYSTEM VEH SPEED VIO/ WHT WIRE VIO/GRY WIRE WATER VALVE ASSEMBLY (LEFT REAR SIDE OF ENGINE COMPT) WHT WIRE WHT/ VIO WIRE WHT/VIO WIRE YEL BLU/ WIRE YEL RED/ WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/VIO WIRE
