BMW 3 series E36 (1990-2000) windscreen cowl panel lock micro- switch Wiring diagram
This page shows the only wiring diagram for the component.windscreen cowl panel lock micro- switch, which is found in the car BMW 3 series E36 (1990-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windscreen cowl panel lock micro- switch (1 of 1)
AIR PUMP
BRN WIRE
BRN/ORG WIRE
BRN/YEL WIRE
CONVERTIBLE TOP ACTUATING SWITCH
CONVERTIBLE TOP CONTROL MODULE
CONVERTIBLE TOP POSITION MICRO- SWITCH
CONVERTIBLE TOP-END POSITION MICRO- SWITCH
CRANKSHAFT POSITION SENSOR SHIELD
CRANKSHAFT POSITION/ RPM SENSOR SHIELD
CYL 1 IGNITION COIL
CYL 2 IGNITION COIL
CYL 3 IGNITION COIL
CYL 4 IGNITION COIL
CYL 5 IGNITION COIL ENGINE CONTROL MODULE (DME)
CYL 6 IGNITION COIL
DATA LINK CONNECTOR
ENGINE CONTROL MODULE (DME)
GROUND
HALL EFFECT CAMSHAFT SENSOR
HIFI AMPLIFIER
HOT FILM AIR MASS METER
HOT FILM AIR MASS METER TRANSMISSION CONTROL MODULE (EGS)
IGNITION COIL SHIELD
NCA WIRE
PASSENGER'S DOOR JAMB SWITCH PASSENGER'S SEAT CONTROL SWITCH
PASSENGER'S SEAT HEATER
PASSENGER'S SEATBACK HEATER
RADIO
REAR DEFOGGER
RESISTOR 240 OHM
RIGHT REAR INTERIOR LIGHT
RIGHT REAR INTERIOR LIGHT RIGHT REAR POWER WINDOW SWITCH (4 DOOR) (AT DOOR)
ROLLOVER SENSOR
SECONDARY AIR PUMP RELAY
SUPPRESSION FILTER
TRANSMISSION CONTROL MODULE (EGS)
UNLOADER RELAY
WINDSCREEN COWL PANEL LOCK MICRO- SWITCH
Go to component -> Ground distribution circuit (3 of 4) -> WINDSCREEN COWL PANEL LOCK MICRO- SWITCH
